NOTE:After turn on SSM-F200,it will be a wireless mode. if you want to use as an external hard drive,do not turn on the device,please connect it to computer with the supplied USB cable,then it will be an external hard drive mode,no wifi signal.Two modes cannot at same time .The power supply port of this product only supports products below 5V 500MAH.
SSK SSM-F200 wireless hard drive supports smart App management, smart upload / download, one touch backup, remote access, multi-people sharing at the same time. Enjoy your media and access your files without wires.
With USB Host to expansion SSK cloud even bigger,support all kinds of USB storage devices， such as USB Disk, hard drive, Card reader
Storage thousands of photos, songs, documents, and movies into this WiFi hard drive.
High Gain WiFi Antenna
Personal WiFi hotspot, up to 300Mbps high speed wireless transmission, without geographical restrictions,remote access and manage the storage freely at any where by PC/Mobile phone, Point to Point confidential transmission to ensure data security
APP Remote Management
Freely access to the hard drive via the SSK CLOUD app in smart devices anywhere anytime.
Small size can be carried at any time, Built-in 3800Mah li-polymer battery, also can be used as power bank, charge your other usb devices
Double Encryption Protection
Set the WiFi password or storage password for the wireless external hard drive and make sure the data safer.
Suppot samba Protocol
Can mirror SSK cloud to a hard disk in the local network.
10 users can access to the storage data at the same time via the APP.
This wireless hard drive is compatible with iOS, Android, Windows, Mac OS, Linux operation system.
Battery: built-in 4000mAh Li-polymer
Interface: USB 3.0 port, RJ45 port
Wireless protocol: IEE 802.11 b/g/n, 2.4G, 300Mbps
Model: SSM – F200
Size: 2.5 inch
Wi-Fi Transmission: 300Mbps
Routing Function: Support AP+Client, AP+WAN Bridge, AP+WAN 3 working mode
Remote Access: Based on UID point to point remote access
Picture Format: JPG, TIFF, JIF, BMP
Audio Format: MP3, AAC, m4a, wav, aiff
Video Format: MP4, MOV, m4v, avi, M-JPEG, RMVB, support 720P and 1080P
Document Format: Keynote, numbers, page, excel , word, pdf, txt, ppt
Connection: Support 10 devices connect at the same time(Max); Support 4 routs of 720P simulcast or 2 routes of 1080P simulcast(Max)
1 x SSM – F200 Wireless Smart WiFi Storage
1 x USB Cable
1 x English User Manual
Hard Drive Working Mode Introduction( Four Modes)
Note: Turn on the Hard drive for Mode 1~3; Turn off the Hard drive for Mode 4.
Mode 1: Direct Wireless Connection
⒈Mobile phone/Tablet PC/Laptop connect the Hard drive’s WiFi hotspot; ⒉Mobile phone and Tablet PC access the Hard Drive via SSKCloud App; ⒊ Laptop access the Hard Drive via SAMBA Connection (IP Address:10.10.10.254); ⒋ All devices have no internet connection.
Mode 2: Home Wi-Fi Network Connection（Via wireless bridge)
⒈ Connect the Hard drive to Router via wireless bridge(User Manual Page 5); ⒉ Mobile phone/Tablet PC/Laptop connect the Router’s WiFi; ⒊ Mobile phone/Tablet PC access the Hard Drive via SSKCloud App; ⒋ Laptop access the Hard Drive via SAMBA Connection (Note: Replace the IP Address 10.10.10.254 with new IP Address, get the new IP address on SSKCloud App: Settings—SAMBA Access ); ⒌ All devices on your home network have the internet and can access the content stored on the Hard Drive.
Mode 3: Home Wi-Fi Network Connection( Via lan cable)
⒈ Connect the Hard drive to Router via LAN cable; ⒉ Mobile phone/Tablet PC/Laptop connect the Router’s WiFi; ⒊ Mobile phone/Tablet PC access Hard Drive via SSKCloud App; ⒋ Laptop access the Hard Drive via SAMBA Connection (Note: Replace the IP Address 10.10.10.254 with new IP Address, get the new IP address on SSKCloud App: Settings—SAMBA Access); ⒌ All devices on your home network have the internet and can access the content stored on the Hard Drive.
Mode 4: USB Connection
⒈Turn off the Hard Drive; ⒉Connect Hard drive to laptop via provided USB3.0 Cable.
Additional: Remote Access Connection
⒈ Connect the Hard drive to Router via LAN cable or wireless bridge(User Manual Page5~6); ⒉ Mobile phone/Tablet PC/Laptop have internet connection(4G or WiFi); ⒊ Mobile phone/Tablet PC remote access via SSKCloud App; ⒋ Laptop remote access via software downloaded from SSK Officiall website.
